CLL24 low loader

Trailers are made according to European standards (paper COC) for fast traffic.

Standard design

Capacity: 24 tons total weight
Load capacity: 16 tons
Dimension platform: 8.50m, 2.53m wide, headboard
Leaf suspended axles
3-axle, fast-traffic axle GRANNING, 105km/h
Tires 215×17.5
Mechanical drive-up ramps
Air brakes + EBS
LED lighting
Choice of 4 colors: red, green, blue and black


Tires 235×17.5 instead of 215×17.5
Hydraulic rams + electro-hydraulic pump 24V
Hydraulic ramps without pump
Opening in floor for fixing post
Fixing post 50cm
Flat center piece in sloping back floor
Lowering in the loading floor + support flat floor
Flip toe ramps (1m longer), 2-piece
Air suspended axles
Extending trailer on flat floor 1m
Flashing light
Widened driveway ramps
Extended drive-up ramps
D-ring in floor
D-ring in side
Hardwood floor
Wide plates + LED lighting
Width hydraulically adjustable ramps
